CSL200A在线智能齿轮双面啮合测量仪

被测齿轮模数（mm)

Module of gear measured(mm)

0.5-5

0.5-8

1-8

1-10

双啮中心距（mm)

Binocular centre distance(mm)

40-150

65-180

75-220

75-260

被测齿轮最大外径（mm)

Max.OD of measured gear(mm)

130

240

320

420

上下两顶尖距离（mm)

Distance between upper and lower tops(mm)

5-280

(可扩展）Extensible

10-450

(可扩展）Extensible

10-500

(可扩展）Extensible

10-550

(可扩展）Extensible

标准齿轮芯轴尺寸：直径/长度（mm)

Standard gear shaft Size:Diameter/Length(mm)

Φ20/160

(可扩展）Extensible

Φ30/240

(可扩展）Extensible

Φ30/240

(可扩展）Extensible

Φ30/240

(可扩展）Extensible
